The TCL HiD43P2 and HiD52P2 are projection televisions with high‑definition picture, digital audio, and multiple input options. The manual guides users through installation, remote‑control functions, picture and audio adjustments, and how to connect external devices such as DVD players and PCs.\n\nIt also covers safety precautions, power‑saving features, troubleshooting steps for common issues like signal interference or picture distortion, and detailed technical specifications of the models. This manual is written in Chinese.
| Screen diagonal (HID43P2) | 109 cm (43 in) |
|---|---|
| Screen diagonal (HID52P2) | 132 cm (52 in) |
| Power consumption | 200 W |
| Input voltage | 160‑240 V, 50 Hz |
| Dimensions (HID43P2) | 932 mm × 530 mm × 1255 mm |
| Dimensions (HID52P2) | 1120 mm × 530 mm × 1375 mm |
| Weight (HID43P2) | 54 kg |
| Video inputs | 4 |
| Audio output power | 20 W × 2 |
| Preset channel memory | 100 channels |
| Reception frequency | 470 MHz (full‑channel cable TV) |
| Supported TV standards | PAL, SECAM, NTSC3.58, NTSC4.43 |
| Supported audio standards | DK, I, B/G, M |
| Standby power consumption | < 3 W |
The TV consumes less than 3 W in standby mode.
The TV has four video inputs and one video output.
