The 16-port 10/100Mbps Ethernet Switch is a plug-and-play Fast Ethernet switch with auto-negotiation (10/100Mbps) and auto-sensing (full-duplex or half-duplex) capabilities for easy installation and operation. Using this switch's switching technology, each network connection can use up to 200Mbps of bandwidth to transfer data, and the total switching bandwidth is 3.2Gbps. Users can use this switch to improve their network performance.
The guide describes how to install the switch on a flat surface or in a rack, connect power and network cables, and configure the device. Installation steps include positioning the unit, securing it with brackets and screws, and selecting the appropriate cable type.
It also explains the meaning of the LED indicators, supported speeds and duplex modes, maximum cable length, and common fault causes with troubleshooting tips. This manual is written in Chinese.
| Number of ports | 16 |
|---|---|
| Supported speeds | 10/100 Mbps |
Each port has an LED indicator that shows link status and whether the connection is full‑duplex (FDX) or half‑duplex.
