This manual introduces the Newman M850 portable MP4 player, covering its features, button layout, and basic usage. It includes safety precautions, charging instructions, and how to lock or reset the device.
The document also lists the technical specifications such as screen size, supported audio/video formats, memory capacity, battery type, and operating temperature, helping users understand the device capabilities. This manual is written in Chinese.
| Dimensions | 90.5mm x 60mm x 14mm |
|---|---|
| Display | 2.5 inch 16‑million color TFT |
| MP3 bitrate | 32 Kbps – 320 Kbps |
| WMA bitrate | 22 Kbps – 128 Kbps |
| Video format | ASF |
| Camera | 2 MP (200万像素) sensor |
| Image format | JPEG |
| Menu languages | Simplified Chinese, English |
| Lyrics format | LRC |
| Memory | 256 MB – 512 MB |
| Headphone output power | 5 mW |
| Frequency response | 20 Hz – 20 kHz |
| Signal‑to‑noise ratio | 86 dB |
| USB interface | USB 1.1 |
| Battery | Lithium‑ion |
| Operating temperature | 0 °C – 40 °C |
Connect the charger to the power outlet and then to the player’s charging port; the red charging indicator will stay lit while charging.
Slide the HQLD switch to the lock position; a lock icon appears on the screen and all buttons are disabled.
Press the FESET reset key once; the device will restart.
