ES-105V is a power module produced by Siemens. It supports 12V, 24V, 48V input and has a maximum output power of 105W.
This manual covers safety precautions, proper installation of water inlet and drain hoses, and detailed operation of the control panel and wash programs. It also includes routine maintenance, filter cleaning, and parts overview.
Troubleshooting sections help diagnose common issues such as power problems, water fill errors, and imbalance during spin cycles, while the specifications table lists electrical and physical parameters of the ES-105V model. This manual is written in Chinese.
| Power supply | AC 110V / 60Hz |
|---|---|
| Power consumption | 530 W |
| Dimensions (H x W x D) | 956 x 598 x 643 mm |
| Weight | 42 kg |
| Standard water consumption per cycle | 207 L |
| Maximum load | 10 kg |
| Wash mode | Vortex |
| Spin mode | Centrifugal |
Connect the inlet hose to the machine’s water inlet port, secure it with the supplied clamp, and ensure the hose is firmly attached to the water tap.
Verify that the water inlet hose is properly connected, the tap is open, and the inlet filter is not blocked.
