This manual describes the parts and functions of the ES-145SBF fully‑automatic washing machine, including the drum, water inlet, drain hose, control panel, and safety mechanisms. It also gives step‑by‑step guidance for installing the machine on a level floor and connecting the water supply and drain.
Operating instructions cover selecting wash programs, adjusting water level, adding detergent, and using the timer and reservation functions. Safety notes warn against using the machine on uneven or damp surfaces, and provide troubleshooting tips for leaks, drainage problems, and power issues. This manual is written in Japanese.
| Power source | 110V/60Hz |
|---|---|
| Power consumption | 550W |
| Water pressure | 0.03‑0.8 NPa (0.3‑8 Kgf/CW) |
| Weight | 55 kg |
| Standard water usage | 285 L per cycle |
| Dimensions (W×D×H) | 642 × 657 × 1012 mm |
Use the adjustment legs: raise the left leg to increase the bubble level and lower the right leg to decrease it until the bubble is centered.
Fit the hose into the faucet, tighten the four fixing screws on the upper clamp, then secure the lower clamp by rotating it clockwise until the hose is firmly held.
