The document provides an overview of the features and characteristics of a product.
The Sampo HD-YC12S is a hot‑water dispenser that supplies boiling and warm water for drinking and cooking. It features a 750 W heating element, a re‑boil function, and a 3.5 L hot‑water capacity.
The manual explains how to operate the unit, how to clean and replace the filter, safety precautions, emergency handling, and after‑sales service procedures. It also lists technical specifications such as power consumption, dimensions and weight. This manual is written in Japanese.
| Input voltage | 110 V 60 Hz |
|---|---|
| Total power consumption | 750 W |
| Re‑boil power consumption | 250 W |
| Keep‑warm power consumption | 50 W |
| Net weight | 6.7 kg |
| Gross weight | 8.0 kg |
| Hot‑water capacity | 3.5 L |
| Ice capacity | 7.0 L |
| Dimensions (W×D×H) | 360 mm × 270 mm × 540 mm |
| Re‑boil temperature | 100 °C |
| Package dimensions | 430 mm × 400 mm × 620 mm |
The filter should be cleaned every 1‑2 months using a soft cloth and avoiding harsh chemicals.
Check that the water tank is filled to the water level; if it is low, add water and try again.
