This is the user manual of Sampo wall-mounted electric heater HX-LA12N, which includes the names of the various parts, installation methods, use methods, safety precautions, maintenance methods/emergency treatment methods, etc.
The HX‑LA12N is a wall‑mounted electric heater designed for residential use. It operates on 110 V/60 Hz and offers three heating modes (cold, warm, hot) with a maximum power of 1200 W.
The manual covers the heater’s parts, step‑by‑step installation guidelines, usage instructions, safety precautions, everyday tips, and maintenance or emergency handling procedures. It also includes warranty information and a timer function for timed operation. This manual is written in Chinese.
| Rated voltage / frequency | 110V/60Hz |
|---|---|
| Rated power consumption | 1200W |
| Dimensions (W×H×D) | 115 mm × 348 mm × 255 mm |
| Power cord length | 1.80 m |
The heater’s rated power consumption is 1200 W.
The power cord is 1.80 meters long.
Install the heater at least 20 cm below the ceiling, 25 cm from each side wall, and the outlet must be at least 150 cm above the floor.
The heater includes a 60‑minute timer; rotate the knob to the desired time and the unit will automatically shut off after that period. In the “continuous” position it runs without stopping.
