F1000-G series variable frequency drive is a AC servo system launched by Ori Transmission Electric Co., Ltd., with the rated input voltage of three-phase 380V and the rated output power of 0.4～400KW. This variable frequency drive adopts vector control technology, and has the characteristics of high performance, high reliability and easy to use.
This manual introduces the F1000‑G series variable frequency drive, covering product overview, technical specifications, safety precautions, and applicable standards. It details the two enclosure types (metal and plastic) and the three structural variants (wall‑mount, cabinet, etc.).
The guide walks the user through panel operation, parameter configuration, function‑code navigation, wiring diagrams, installation steps, and common fault handling. Appendices include a quick‑reference function‑code table, product overview, brake resistor selection, and Modbus communication details. This manual is written in Chinese.
| Power range | 0.4–400 kW |
|---|---|
| Input voltage | 3‑phase 380 V ±15 % (50/60 Hz) or 1‑phase 220 V ±15 % (50/60 Hz) |
| Output frequency range | 0.50–400 Hz |
| Maximum overload capacity | 150 % of rated current for 1 min |
| Ground resistance limit | ≤ 4 Ω |
| Operating temperature range | -10 °C to +50 °C |
The ground resistance must not exceed 4 Ω.
It can operate between –10 °C and +50 °C.
The drive provides more than 140 function codes divided into nine sections.
The series covers power ratings from 0.4 kW up to 400 kW.
