This manual provides step‑by‑step instructions for installing and using the Sampo CT‑W110L telephone. It includes details on power connections, dimensions, frequency settings, and how to configure date, time, and regional codes.
The guide also explains how to pair multiple sub‑units, use the call‑display service, adjust volume and other functions, and offers a troubleshooting section with emergency handling procedures. This manual is written in Chinese.
| Sub‑unit power consumption | 9 V / 100 mA ≈ 0.85 W |
|---|---|
| Mother unit dimensions | 700 × 195 × 185 × 60 mm |
| Sub‑unit dimensions | 200 × 90 × 90 × 190 mm |
| Mother unit RF frequency | 46.610 – 46.970 MHz (10 channels) |
| Sub‑unit RF frequency | 49.670 – 46.970 MHz (10 channels) |
| RF frequency error (mother) | < 500 Hz |
| Transmission power | < 10 mW |
| DTMF tone error | ≤ 1.5 % |
In standby mode press the [醒] button, then enter the eight‑digit date (YYYYMMDD) followed by the hour and minute digits; the display will confirm successful setting.
The device transmits at less than 10 mW.
