This document is an explanation of the features and characteristics of the product, describing its functions, performance, and advantages.
This manual begins with safety instructions, including the use of the supplied charger, avoiding metal contacts, and keeping the device away from explosive or medical environments. It also lists the operating temperature (+5 °C to +45 °C) and humidity (5 %–85 %).
The guide then covers installation of the base unit, battery insertion for the handset, LCD display functions, and detailed usage instructions such as dialing, call handling, and managing multiple handsets. Troubleshooting tips and after‑sales service contact information are provided at the end. This manual is written in Chinese.
| Base power supply | DC 6.5 V, 1300 mA, 15 W (standby), AC 110‑120 V 60 Hz |
|---|---|
| Phone battery voltage | DC 2.4 V |
| Operating frequency | 1880‑1895 MHz |
| Base dimensions | 88 mm × 126 mm × 46 mm |
| Base weight | 120 g |
| Handset dimensions | 49 mm × 152 mm × 20 mm |
| Operating temperature | +5 °C to +45 °C |
| Relative humidity | 5 % to 85 % |
| Maximum standby time | 150 hours |
| Talk time | 10 hours |
| Indoor communication range | 50 m |
| Outdoor communication range | 300 m |
Connect the power cord to an AC 110‑120 V outlet, then connect the telephone line to the base as shown in the installation steps.
The handset can remain in standby for up to 150 hours.
The device operates between +5 °C and +45 °C.
The base can be expanded to support up to five handsets using the GAP function.
