Provides general information about electronic brake units frenomat® and frenostat®, including cUL approval, EU Declaration of Conformity, line choke, mechanical stability certification, application/operating principle, frenomat 2 brake unit, frenostat 2000 brake unit and technical data.
The document provides technical specifications, installation guidance, and application examples for Hilger & Kern's electronic brake units – the compact Frenomat 2 and the higher‑power Frenostat 2000. It includes compliance information, dimensions, wiring diagrams, and commissioning instructions.
The brake units are CUL‑listed, feature integrated line chokes, LED status displays, and built‑in overheating and standstill monitoring, making them suitable for a range of three‑phase AC motor applications.
| Frenomat 2 power rating | up to 3 kW |
|---|---|
| Frenomat 2 width | 55 mm |
| Frenomat 2 mounting | snap‑fitting on DIN rails |
| Frenostat 2000 sizes | 4 different sizes |
| Overheating protection (both units) | integral temperature‑measuring function, LED “O” flashes on overheat |
| Integrated line choke | built into the brake unit enclosure |
The Frenomat 2 is only 55 mm wide.
Yes, the Frenomat 2 includes an integrated line choke within its enclosure.
