Elmasonic S 100 H ultrasonic cleaning machine is one of the Elmasonic S series products. The series has 16 models with water tank capacities ranging from 0.5 liters to 90 liters. The series uses microprocessor-controlled ultrasonic cleaning technology and advanced sweep technology, which are efficient, safe and convenient.
The Elmasonic S 100 H is a micro‑processor‑controlled ultrasonic cleaning device featuring a 0.5‑90 L tank range, LED display, sweep‑function and degas options for laboratory use. It offers user‑friendly controls, a sealed electronics compartment and ergonomic handling.
Technical data include a 37 kHz ultrasonic frequency, 550 W total power consumption, stainless‑steel tank, temperature setting from 30 °C to 80 °C in 5 °C steps, and IP20 protection. The unit operates on 100‑120 V or 220‑240 V mains and weighs about 5.9 kg. This manual is written in German.
| Netzspannung (Vac) | 100-120 V / 220-240 V |
|---|---|
| Gewicht (kg) | 5.9 |
| Netzfrequenz (Hz) | 50/60 |
| Material Wanne | Edelstahl |
| Ultraschall‑Frequenz (kHz) | 37 |
| Leistungsaufnahme gesamt S 100 H (W) | 550 |
| Ultraschallleistung effektiv (W) | 150 |
| Heizleistung (W) | 400 |
| Schutzklasse | IP20 |
It operates at a frequency of 37 kHz.
The S 100 H model has a total power consumption of 550 W.
