This manual covers the installation and wiring of the CK‑W606ML unit, including power connection, remote‑control battery installation and positioning in a suitable environment. Detailed steps guide you through turning the device on, selecting AM/FM stations, and using CD, MP3 and USB playback modes.
Safety warnings, cleaning instructions, and a troubleshooting guide are provided to help avoid damage or injury. Technical specifications such as power requirements, dimensions and audio output are listed for reference. This manual is written in Chinese.
| Power supply | AC 110V 60Hz |
|---|---|
| Power consumption | 25 W |
| Audio output power | 2 × 2 W RMS |
| AM receive frequency | 530‑1710 kHz |
| FM receive frequency | 87.5‑108 MHz |
| Main unit dimensions (W × L × H) | 253 mm × 135 mm × 149 mm |
Press the POWER/STANDBY button and switch it to ON; the unit will then be powered.
While in program playback mode, press the STOP button to delete the stored program.
Install one cell battery with the correct polarity into the remote control.
