This manual explains safe operation of the Sampo TINSC2263Y1 multimedia LCD, including warning symbols, power requirements, and handling precautions. It details how to protect the LCD panel, avoid electric hazards, and what to do in case of faults.
Installation instructions cover wall‑mounting using the VESA 200 mm × 200 mm pattern, required clearances, and proper positioning. The guide also includes cleaning and maintenance procedures, such as using a soft dry cloth and avoiding solvents, as well as steps to follow after prolonged inactivity. This manual is written in Chinese.
| Input voltage | AC 100‑240 V 50/60 Hz |
|---|---|
| VESA mounting pattern | 200 mm × 200 mm |
It operates on AC 100‑240 V at 50/60 Hz.
Use a VESA‑compatible wall mount with a 200 mm × 200 mm mounting hole pattern.
Turn off the power, wait about 30 seconds, then turn it on again and retry operation.
