This is the operating instructions for SONY PMA-SA1
This manual covers safety precautions, panel control designations, and detailed connection diagrams for the Denon PMA‑SA1 integrated stereo amplifier. It explains how to install the unit, select inputs, adjust volume and balance, and use the phono equalizer and balanced inputs.
Additional sections include a block diagram, troubleshooting tips, and full technical specifications such as power output, distortion, speaker impedance, power consumption, dimensions and weight. The document is multilingual, with the English version presented here.
| Nominal Power Output (8 Ω) | 50 W per channel |
|---|---|
| Nominal Power Output (4 Ω) | 100 W per channel |
| Total Harmonic Distortion | 0.007 % (–3 dB) |
| Speaker Impedance Range | 4 Ω – 16 Ω |
| Power Consumption | 230 W (IEC) |
| Dimensions (W × H × D) | 434 mm × 181 mm × 508 mm |
| Weight | 30.0 kg |
| Phono Input Sensitivity | 2.5 mV / 47 kΩ |
| Signal‑to‑Noise Ratio (Phono) | 88 dB |
The amplifier delivers 50 W per channel into an 8 Ω load.
The total harmonic distortion is 0.007 % (–3 dB).
