This manual introduces the installation and use methods of digital hard disk recorders, including pre-installation, basic operations, alarm wiring instructions, hard disk recorder device connection diagram, etc.
The guide begins with safety notes, specifying temperature limits, ventilation requirements, and handling precautions before installation. It then covers preliminary preparation, unboxing inspection, and detailed steps for installing SATA hard disks in 1U and 1.5/2U units.
Subsequent sections describe front‑panel button functions, rear‑panel port labels, alarm input/output wiring, network configuration, PTZ camera connection, and client/IE browser operation, ending with a brief menu structure overview. This manual is written in Chinese.
| Operating temperature | 0℃‑55℃ |
|---|---|
| Power input | DC 12V/2A, DC 12V/3.3A, DC 12V/4A, AC 220V |
| Default IP address | 192.168.1.156 |
| Maximum client connections | 20 |
| TCP port | 9001 |
| UDP port | 9002 |
| HTTP port | 80 |
The device should be placed and used within 0 °C to 55 °C.
Remove the side screws, open the case, place the hard disk in the bay, secure it with screws, and connect the data and power cables before closing the cover.
