This document introduces the features and characteristics of the 7-inch serial LCD display module independently developed and produced by Shanghai Jingao Information Technology Co., Ltd., including color depth, communication interface, storage capacity, display speed, etc.
The M070S65-H1 series is a 7‑inch serial LCD display module developed by Shanghai Chang'ao Information Technology Co., Ltd. It supports graphic drawing commands, touch screen input and flash image storage, and is used in medical and industrial control applications.
The manual provides an overview of features, ordering options, mechanical dimensions, electrical interface standards, and a full command reference (MIS V1.0) for developers integrating the module with micro‑controllers. This manual is written in Chinese.
| Color depth | 65536 colors |
|---|---|
| Color format | RGB565 |
| Default baud rate | 9600 bps |
| Full‑screen image storage | Up to 50 images |
| Small‑image storage | Up to 192 images |
| Display size | 7.0 inch |
| Contrast ratio | 500:1 |
| Module thickness | < 18 mm |
The default baud rate is 9600 bps.
The module can store up to 50 full‑screen images.
The contrast ratio is 500:1.
