This manual provides instructions for installing the chipset and sound‑card drivers for the Lenovo P6VXM2 motherboard, as well as configuring the system jumpers and front‑panel connectors. It includes step‑by‑step guidance for Windows 95/98/NT environments.
The document lists the motherboard’s connectors and jumper functions, such as CPU fan, DIMM slots, IDE, ATX power, AGP, PCI, ISA, CMOS clear, BIOS write‑protect, and Wake‑On‑LAN/Modem pins, helping users correctly assemble and troubleshoot the board. This manual is written in Chinese.
| CPU Socket | PGA370 |
|---|---|
| DIMM Slots | 2 |
| IDE Connectors | IDE1L, IDE2 |
| Floppy Drive Connector | FDD1 |
| ATX Power Connector | ATXI1 |
| AGP Slot | AGP1 |
| PCI Slots | PCI1, PCI2, PCI3 (32‑bit) |
| ISA Slot | ISA1 |
| CMOS Clear Jumper | JP1 |
| BIOS Write‑Protect Jumper | JP18 |
| Wake‑On‑LAN Connector | WOL1 |
| Wake‑On‑Modem Connector | WOMI1 |
The JP1 jumper is used to clear the CMOS.
