SBC6000_LVDS is a board that converts LCD TTL signal to LVDS signal. It is compatible with SBC6000X and SBC6845 mainboards and is compatible with two LVDS screens, TM104SDH01 and TM104SDH03. These two screens are both 10.4-inch LCD screens with a resolution of 800x600, but differ in backlight voltage.
The SBC6000_LVDS board converts LCD TTL signals to LVDS signals and supports 10.4‑inch LCD panels with a resolution of 800×600. It is compatible with SBC6000X and SBC6845 motherboards and works with LVDS modules TM104SDH01 and TM104SDH03.
The manual describes each connector (J2 LVDS, J5 Backlight1 12 V, J7 Backlight2 19 V, J10 TTL, J20 Touch), provides pin‑out tables, wiring diagrams for connecting to the SBC6845 board, and details the one‑year warranty and technical support options. This manual is written in Chinese.
| J2 Interface | LVDS signal |
|---|---|
| Backlight1 Voltage | 12V |
| Backlight2 Voltage | 19V |
| LCD Size | 10.4 inch |
| Resolution | 800x600 |
| Compatible Motherboards | SBC6000X, SBC6845 |
| LVDS Modules | TM104SDH01, TM104SDH03 |
| Warranty | 1 year |
It converts LCD TTL signals to LVDS signals.
The product includes one year of free technical support.
