This is the instruction manual of Model 6300 digital power meter
This manual covers the Kyoritsu 6300 Power Meter, a clamp‑type instrument for measuring AC voltage and current. It lists the available current ranges (up to 500 A) and voltage ranges (up to 500 mV) and describes how to connect the meter for single‑phase and three‑phase measurements.
The document includes safety guidelines, installation steps, and basic operation procedures. Technical specifications such as frequency response, accuracy, and environmental limits are provided, along with troubleshooting tips and warranty information.
| Current measurement range | 0 ~ 500 A (50/60 Hz) |
|---|---|
| Voltage measurement range | AC 0 ~ 500 mV (500 mV/500 A) |
| Frequency response | 40 Hz ~ 1 kHz |
The meter can measure currents up to 500 A at 50/60 Hz.
It operates from 40 Hz to 1 kHz.
