This is the user manual for the Haier KFR-72GW/03EAF13 air conditioner. It introduces the product's function features, use methods, precautions and maintenance methods.
This manual provides step‑by‑step installation instructions for the Haier KFR‑72GW/03EAF13 and KFR‑72GW/03GCC12 split‑wall air conditioners. It covers electrical requirements, mounting of indoor and outdoor units, refrigerant piping, drainage, and final commissioning.
The guide also includes operating instructions such as timer setup, clock calibration, health‑flow mode, emergency operation, cleaning of filters, and troubleshooting tips to ensure safe and efficient performance. This manual is written in Chinese.
| Model | KFR-72GW/03EAF13 / KFR-72GW/03GCC12 |
|---|---|
| Power (W) | 2300 / 2350 |
| Cooling capacity (kW) | 2.257 / 2.150 |
| Airflow (m³/h) | 1200 |
| Indoor noise (dB(A)) | 45 high / 41 mid / 40 low / 37 quiet |
| Outdoor noise (dB(A)) | 55 |
| Indoor dimensions (mm) | 1140×320×240 / 1137×320×258 |
| Outdoor dimensions (mm) | 860×730×308 / 948×830×340 |
| Indoor weight (kg) | 18.5 |
| Outdoor weight (kg) | 60 / 73 |
