QD-2400GS Ethernet switch provides 24 10/100/1000M auto-sensing UTP ports, strong functions make your network more flexible, secure and reliable.
This manual describes the QD-2400GS Ethernet switch, which offers 24 10/100/1000 Mbps RJ45 ports, web‑based management, and RS232 serial control. It outlines hardware features, power requirements, and safety guidelines for installation.
The document details configuration options such as VLANs, LACP aggregation, RSTP, 802.1X authentication, IGMP snooping, QoS, rate limiting, storm control, and port mirroring. It also covers monitoring statistics, firmware upload, factory reset, and command‑line access via RS232. This manual is written in Chinese.
| Number of Ethernet ports | 24 |
|---|---|
| Port speed | 10/100/1000 Mbps |
| Power input | 110‑260 V AC, 50‑60 Hz |
| VLAN support | IEEE 802.1Q Tag‑based VLAN |
| Link aggregation (LACP) | Supported |
| RSTP support | Supported |
| 802.1X authentication | Supported |
| IGMP snooping | Supported |
| QoS (IEEE 802.1p) | Supported |
| Default IP address | 10.10.10.168 |
The switch provides 24 RJ45 ports that support 10/100/1000 Mbps speeds.
The default IP address is 10.10.10.168.
Select the "Factory Default" option in the maintenance menu to restore the default configuration.
Microsoft Internet Explorer 5.0 or later and Netscape Navigator 6.0 or later are supported.
