TKS-764B is a real-time online emulator launched by Guangzhou Zhiyuan Electronic Co., Ltd. It fully supports PHILIPS 51LPC series chip emulation. The emulation performance has been comprehensively optimized to ensure that users have more convenient operation and real emulation effects. This document details the use of TK764B emulator
The TKS-764B emulator is a hardware simulation tool for Philips SILPC series microcontrollers. It supports the P87LPC768 and P87LPC769 chips and integrates with Keil development environments (versions 6.2 and 7.0). The guide explains the device’s hardware connections, power requirements, and software configuration.
Key sections include pre‑use safety checks, detailed Keil setup steps, hardware wiring (20‑pin DIP socket, RS‑232 interface up to 1.5 m), and a troubleshooting chapter that addresses communication failures and single‑step execution issues. This manual is written in Chinese.
| Supported SILPC chips | P87LPC768 (TKS-764B‑768) and P87LPC769 (TKS-764B‑769) |
|---|---|
| Supported SILPC chips | P87LPC769 (TKS-764B‑769) |
| Power supply | AC 220 V |
| Connector type | 20‑pin DIP socket |
| Additional connector | 40‑pin flat package |
| Keil version support | Versions 6.2 and 7.0 |
| Compatible microcontroller series | Philips SILPC series |
