This document is about the manual of 13537695550 Chinese font LCD display. The LCD display can perform graphic display and display Chinese characters. It consists of a 192×64 dot matrix LCD display and row driver/column driver. The display can be controlled by an external CPU through serial or parallel interface. Its main technical parameters include +5V power supply, 192×64 dot display, 8192 Chinese characters and 128 characters ROM storage, and a working temperature range of -20℃ to +70℃.
The 19264M is a graphic dot‑matrix LCD module with a 192 × 64 pixel display. It can show graphics and up to 8 × 4 Chinese characters (16 × 16 dot matrix) and is driven by a row/column driver architecture. The module can be controlled by an external CPU via either a parallel or serial interface.
The manual describes the module's hardware components, external pin assignments, command set (basic and extended), timing diagrams, and provides example applications. It also includes details on power requirements, operating temperature range, and ROM character tables. This manual is written in Chinese.
| Power supply | +5 V (VDD) |
|---|---|
| Display resolution | 192 × 64 dots |
| HCGROM characters | 128 characters (16 × 8 dots) |
| Operating temperature | -20 °C ~ +70 °C |
| Storage temperature | -30 °C ~ +180 °C |
| Pixel pitch | 0.508 mm × 0.508 mm |
The module requires a +5 V supply on the VDD pin.
The module can be controlled via a parallel interface or a serial interface.
The display resolution is 192 columns by 64 rows (192 × 64 dots).
