SV100 series general frequency converter adopts unique control method to achieve high torque, high precision, wide speed drive, meeting the trend of high performance of general frequency converter; it has excellent anti-tripping performance and adaptability to harsh power grid, temperature, humidity and dust, greatly improving product reliability. This manual provides users with installation wiring, parameter setting, fault diagnosis and elimination and daily maintenance related precautions.
The Kinco SV100 series is a modular, high‑performance variable frequency drive designed for a wide range of industrial applications. It offers PWM control, flexible I/O, and multiple control modes such as open‑loop vector, closed‑loop vector, and speed control.
This manual provides safety guidelines, product specifications, installation and wiring instructions, operation procedures, fault diagnosis, and maintenance recommendations to ensure reliable and safe operation of the SV100 drive. This manual is written in Chinese.
| Input rated voltage | 380 V – 440 V (three‑phase) |
|---|---|
| Input voltage range | 320 V – 460 V |
| Input frequency | 50 Hz / 60 Hz |
| Output frequency range | 0 Hz – 300 Hz |
| Control method | No‑PG vector control, VA control |
| Cooling method | Air‑cooled with fan control |
| Installation type | Wall‑mountable |
The drive accepts an input voltage between 320 V and 460 V.
The maximum output frequency is 300 Hz.
