This document introduces the application scope, features, and specifications of the ZW-9018G external car GPS navigation. The product features high integration, rich interfaces, support for various video output formats and resolutions, multimedia playback, text reading and image browsing, navigation voice priority function, remote control and touchscreen operation, etc.
The ZW‑9018G is an external GPS navigation unit designed to integrate with automotive DVD systems. It offers multiple video outputs (RGB, YPbPr, S‑VIDEO, CVBS), dual‑channel audio, multimedia playback, and a touch‑screen interface.
The document provides detailed hardware specifications, GPS module parameters, wiring diagrams, software installation steps, touchscreen calibration, audio playback instructions, remote‑control functions and a packaging list, helping users set up and operate the device safely. This manual is written in Chinese.
| CPU frequency | 400 MHz |
|---|---|
| Main chip model | SAMSUNG S3C2440A-40 |
| Memory | 64 MB |
| Storage capacity | 64 MB (expandable to 4 GB) |
| Operating system | WINCE5.0 NET |
| Audio output | Dual‑channel CD quality |
| Video output types | Composite video / Analog RGB |
| Average power consumption | 3 W (standby < 50 mW) |
| Operating temperature range | -40 °C to +80 °C |
| Dimensions | 55 mm × 45 mm × 8 mm |
| Operating voltage | DC 12 V |
The device operates from a DC 12 V power source.
It supports 20 GPS tracking channels.
The unit uses an external active ceramic antenna.
