The V2406 series embedded computers are based on the Intel Atom N270 x86 processor, with 4 RS-232/422/485 serial ports, dual LAN ports and 3 USB 2.0 ports. In addition, the V2406 computers also provide VGA and DVI-I outputs and are certified to EN 50155, making them ideal for industrial applications such as rail transportation.
The V2406 series is an industrial‑grade embedded computer built around an Intel Atom N270 1.6 GHz processor. It supports dual video output (VGA + DVI‑I), two 10/100 Mbps Ethernet ports with M12 connectors, four RS‑232/422/485 serial ports, six digital inputs, two digital outputs, and three USB 2.0 hosts. The unit ships with either Linux or Windows Embedded Standard 2009 pre‑installed and offers a 1 GB Compact Flash onboard storage with an additional CF slot for expansion.
Designed for harsh environments, the V2406 complies with EN 50155, operates from –40 °C to 70 °C (wide‑temperature model), and draws a maximum of 2.6 W from a 12‑48 V DC supply. The chassis is aluminum, weighs about 2 kg, and measures 250 × 57 × 154 mm. Optional accessories include power adapters, mounting kits, and cable assemblies. This manual is written in Chinese.
| Processor | Intel Atom N270 1.6 GHz |
|---|---|
| Memory | DDR2 up to 2 GB |
| Serial Ports | 4 × RS‑232/422/485 |
| Digital I/O | 6 DI, 2 DO |
| Operating Temperature (wide‑range model) | -40 °C to 70 °C |
| Power Input | 12 V–48 V DC (M12 connector) |
| Dimensions | 250 × 57 × 154 mm |
| Certification | EN 50155 |
It uses an Intel Atom N270 1.6 GHz processor.
It can operate from –40 °C to 70 °C.
