TI40/TI45 series infrared thermal imagers are high resolution/low noise Vox detectors for capturing high-quality images, covering a wide range of industrial applications, high temperature options up to 1200 °C.
The Fluke TI40/TI45 series infrared thermal imaging instrument provides a 160 × 120 detector with high temperature sensitivity (0.08 °C NETD) and a wide temperature range, enabling detailed thermal analysis in industrial settings. The device runs a Windows CE menu interface and includes IR‑Fusion technology that combines visible‑light and infrared images for easier interpretation.
Typical applications include preventive maintenance, industrial maintenance, quality control, and process monitoring. The manual also offers ordering information for various lens options (10.5 mm, 20 mm, 54 mm) and high‑temperature accessories up to 1200 °C. This manual is written in Chinese.
| Detector resolution | 160 × 120 |
|---|---|
| Temperature sensitivity (NETD) | 0.08 °C |
| Temperature range | -20 °C to +600 °C |
| High‑temperature option | up to 1200 °C |
| Lens options | 10.5 mm, 20 mm, 54 mm |
It uses a 160 × 120 detector.
The temperature sensitivity is 0.08 °C NETD.
Lens options are 10.5 mm, 20 mm, and 54 mm.
