This manual introduces the usage of Lenovo L215p Wide Monitor Webcam, including system requirements, product features, installation guide, application software user guide, FAQ, etc.
This manual provides an overview of the Lenovo L215p Wide webcam, including its CMOS sensor, Full HD resolution, automatic white balance, and built‑in microphone. It lists the hardware and software requirements needed to operate the camera on Windows XP SP1 or later and Windows Vista.
The guide walks you through driver installation and removal, explains how to use the provided vmcap application for preview, capture settings, and recording, and answers common troubleshooting questions such as image artifacts, automatic stop of recording, and device detection errors. This manual is written in Chinese.
| CPU Requirement | Pentium 4 1.8 GHz or higher |
|---|---|
| Memory Requirement | 512 MB or more |
| Interface | USB 2.0 (compatible with USB 1.1) |
| Supported Operating Systems | Windows XP SP1 or later, Windows Vista |
| Maximum Image Resolution | 1920 × 1080 (Full HD) |
| Maximum Frame Rate | 30 fps |
| Image Sensor | CMOS, 300 k pixels |
在 Option\Video Capture Filter 中切換 50 Hz/60 Hz，或關閉室內燈光、降低外部光源、拉上窗簾以消除橫紋。
當磁碟空間已滿或設定的錄影時間到達時，系統會自動停止錄製。
先用手遮擋鏡頭再放開讓相機自動調節，或在 Option\Video Capture Filter 中調整亮度與對比度。
