This is a product manual for a wall-mounted bracket. It mainly introduces the safety instructions for using the product, the disassembly and installation methods of the product, and the maintenance methods of the product.
This guide provides safety precautions that must be observed before installing the wall‑mount bracket, including reading the safety notes, avoiding installation near fire sources, and ensuring the wall can support the load. It also explains that the bracket must not be modified or disassembled and that proper cleaning and handling are required.
The document details the components supplied, the assembly sequence, torque specifications, angle‑adjustment procedure, and wiring connections for the plasma TV. It includes dimension tables, mounting‑hole locations, and recommended screw sizes for secure installation. This manual is written in Japanese.
| Weight | ≈ 3.2 kg |
|---|---|
| Mounting holes | 10 holes (5 upper, 5 lower) |
| Screw size | 6 mm diameter (or larger) appropriate for wall material |
| Torque (main bolts) | 1.5 N·m |
| Torque (adjustment screw) | 1.2‑1.5 N·m |
The bracket weighs approximately 3.2 kg.
