MSP40 series silicon pressure sensors can provide accurate, linearly related voltage outputs to external sensing pressure. This series of standard packaging uncompensated sensor components provides users with flexible usage options, allowing users to easily design and add subsequent signal processing circuits.
The MSP40 series silicon pressure sensors from MEM Sensing Microsystems deliver a linear voltage output proportional to measured pressure. Built with MEMS technology, the sensors feature low cost, standard surface‑mount or through‑hole packages, and a typical full‑scale output of 75 mV.
The document lists detailed electrical parameters, three selectable pin configurations, mechanical dimensions for GSR, GDR and GDF packages, and an ordering guide. Application examples include electronic blood pressure monitors, automotive fuel‑level monitoring, and HVAC systems. This manual is written in Chinese.
| Full‑scale output (typical) | 75 mV |
|---|---|
| Non‑linearity (max) | ±0.25 % |
| Operating temperature range | -40 °C to +125 °C |
| Pressure range | 0 – 40 kPa |
| Supply voltage (VOP) | 5 V – 15 V |
| Supply current (IOP) | 1 mA – 3 mA |
| Overload pressure | 120 kPa |
| Burst pressure | 200 kPa |
The typical full‑scale output is 75 mV.
The sensor operates from –40 °C to +125 °C.
GSR, GDR, and GDF packages are offered.
Temperature compensation can be performed by adding passive components that generate a compensating voltage.
