The STN2180A is a hand‑move SPDT switch. This manual provides the key electrical specifications such as frequency range, insertion loss, isolation and power handling, as well as the mechanical dimensions of the device.
The document also lists performance parameters like average power, impedance and compatibility notes, helping users select and install the switch correctly in their systems. This manual is written in Japanese.
| Frequency range | DC‑5GHz |
|---|---|
| Insertion loss | 1.3 dB |
| Return loss | 0.3 dB |
| Isolation | 5 dB (DC‑1GHz) |
| 3 dB bandwidth | 1‑5 GHz |
| Power handling | 2.5 kW |
| Average power | 5 W |
The switch operates from DC up to 5 GHz.
The insertion loss is 1.3 dB.
It can handle up to 2.5 kW of power.
