XELTEK USB interface intelligent universal programmer is a powerful, high-performance programmer that features fast programming speed, wide range of supported devices, and automatic detection of chip insertion errors.
The XELTEK LRS1381 is a CE‑certified USB interface programmer that supports a wide range of memory and logic devices, including FLASH, EPROM, EEPROM, MCU and PLD. It offers high‑speed programming, low‑voltage operation down to 1.5 V, automatic chip detection, over‑current protection and logic testing functions.
The accompanying software runs on Windows 98/ME/NT/2000/XP (Chinese/English) and provides project management, batch processing, history records, automatic voltage verification and an open API for custom data handling. The manual details device setup, programming procedures, timing specifications and warranty information. This manual is written in Chinese.
| Input voltage | 100‑240 V AC, 50/60 Hz |
|---|---|
| Output voltage / current | 12 V DC / 2 A |
| Dimensions | 178 mm × 130 mm × 40 mm |
| Supported device voltage | 1.5 V – 5 V |
| USB interface | USB 1.1 |
| Supported packages | DIP, SDIP, PLCC, JLCC, SOIC, QFP, TQFP, PQFP, VQFP, TSOP, SOP, TSOPII, PSOP, TSSOP, SON, EBGA, FBGA, VFBGA, uBGA, CSP, SCSP, … |
The software runs on Windows 98, ME, NT, 2000 and XP (both Chinese and English versions).
A one‑year warranty is offered from the date of purchase with an invoice; adapters and sockets are consumables and are not covered.
