FS4100 series 2.5G filtering device user manual, detailed introduction of FS4100 series OC48 filtering device hardware structure and installation methods, and also explained how to configure various features on FS4100 series OC48 filtering device.
The FS-4100 series is a 2.5 G bit SONET/SDH network access filtering device designed for system integrators and sites that need packet analysis, classification, and forwarding. It features four 2.5 G inputs and four Gigabit Ethernet outputs, supporting rule‑based filtering and load‑balancing across ports.
The manual is organized into eight chapters covering product overview, hardware structure, installation steps, command‑line configuration, web‑based configuration, RPC configuration, output packet format, and a FAQ section that answers common installation and operation questions. This manual is written in Chinese.
| Number of 2.5G inputs | 4 |
|---|---|
| Number of Gigabit outputs | 4 |
| Supported classification fields | Destination IP, Source IP, Protocol, Destination port, Source port |
| Load‑balancing algorithms | SIP, DIP, SIP+DIP, custom |
| Maximum line rate | 2.5 Gbps |
