The IKO SA200DE alignment stage is a low‑height, ultra‑compact X‑Y‑θ motion platform that uses two linear motors and crossed‑roller guides. It provides high positioning accuracy through a full closed‑loop control with an optical linear scale.
The stage is suited for semiconductor manufacturing, flat‑panel display alignment, and precision inspection systems. Various model combinations (SA120DE, SA65DE, etc.) allow customization of axes, thrust, and travel range.
| Rated thrust | 35 N |
|---|---|
| Operative stroke length | 10–20 mm |
| Mass of moving part | 0.17 kg |
| Total mass | 0.35 kg |
| Ambient temperature and humidity | 0‑40 °C, 20‑80 % RH |
Effective thrust is the effective value of the thrust required in a given operation pattern.
Dynamic load mass is the maximum weight that permits obtaining the required acceleration and deceleration.
