This document provides instructions and information about the usage and features of Creative's new digital player ZEN Vision:M. It includes an overview of the player, instructions on using the navigation controls, software installation, charging the device, and customization options. Additionally, it explains how to connect the player to a TV.
This manual introduces the Creative ZEN Vision:M digital media player and explains how to operate it safely. It covers the device’s controls, charging, connecting to a computer or TV, and basic troubleshooting.
Key sections include navigation controls, step‑by‑step setup, transferring music, video and photos, personalization options, and a detailed specifications table. Legal and copyright information is also provided. This manual is written in Chinese.
| Battery | 1 rechargeable lithium battery |
|---|---|
| Power Input | DC IN 5 V (USB bus power when connected to computer) |
| Audio Playback Formats | MP3 up to 320 kbps, WMA up to 320 kbps with DRM, WAV |
| Video Playback Formats | MPEG‑1, MPEG‑2, MPEG‑4‑SP, WMV9, MJPEG |
| Image Formats | JPEG Baseline up to 16 MP, JPEG Progressive up to 4 MP |
| Signal‑to‑Noise Ratio | 97 dB |
| Channel Separation | -70 dB (linear output) |
| Frequency Response | 20 Hz ~ 20 kHz |
| Harmonic Distortion | < 0.1 % |
| Headphone Jack | 3.5 mm stereo, 25 mW per channel |
| LCD Display | 2.5" (63.5 mm) 320 × 240 pixels, 262 144 colors |
Connect the player to a computer’s USB port with the supplied USB cable; the power LED will flash and the LCD will show a charging icon. Full charge takes about 5 hours.
