Declaration of Conformity We Manufacturer ZIPPY TECHNOLOGY CORP. 10F No.50 MIN CHYUAN RD. SHIN-TIEN TAIPEI HSIEN TAIWAN R.O.C. declare that the product (description of the apparatus system

R2K-5C00V is a switching power supply manufactured by ZIPPY TECHNOLOGY CORP. It meets the requirements of 2004/108/EC-EMC directive, as well as EN 55022 : 2006+A1/2007, EN 55024 : 1998+A1/2001+A2/2003, EN 61000-4-2 : 2009, EN 61000-4-3 : 2006+A1/2008, EN 61000-4-4 : 2004, EN 61000-4-5 : 2006, EN 61000-4-6 : 2007, EN 61000-4-8 : 1993+A1/2001, EN 61000-4-11 : 2004, EN 61000-3-2 : 2006 and EN 61000-3-3 : 2008.

About this manual

The document declares that the Zippy Technology MIN2-6251P switching power supply meets the requirements of the 2004/108/EC EMC Directive and related EN standards. It lists the applicable EMC standards (EN 55022, EN 55024, EN 61000 series) and provides details of the test procedures and results.

Test data, equipment lists, and measurement setups are documented, including conducted and radiated emission tests, ESD, surge, and harmonic current assessments. The report is signed by Zippy Technology personnel and dated October 25, 2010.

What's inside

Test Report Certification
General Information
Test Methodology
Electronic-Magnetic Interference Test
Conducted Power Line Test
Radiated Emission Test
ESD Measurement
Electrical Fast Transient Measurement
Harmonic Current Requirements
Voltage Fluctuation Test

Specifications

Input Voltage	115Vac/60Hz, 230Vac/50Hz

Frequently asked questions

What standards does the MIN2-6251P comply with?

It complies with EN 55022, EN 55024 and the EN 61000 series of EMC standards.

When was the compliance testing performed?

The testing was performed on October 25, 2010.

What is the model number of the switching power supply?

The model number is MIN2-6251P.
