AP1132 is a high-precision portable biosignal measurement system produced by Toshiba Corporation. It can be used to collect various physiological signals such as EEG, ECG, EMG, etc. The system adopts 32-channel high-precision A/D converters, the sampling frequency can reach 2000Hz, and supports PC/CompactFlash® storage cards, which can record 24 hours of data continuously.
The Polymate AP1132 is a lightweight, battery‑operated bio‑signal recording device that can capture EEG, EMG, ECG, eye‑movement, respiration, and other signals for more than 24 hours. It connects to a PC via USB for configuration, real‑time monitoring, and data storage on a CompactFlash card or PC hard drive.
The manual provides details on the included software (AP Monitor/AP Viewer), hardware options, recommended PC environment, and technical specifications such as channel count, sampling rate, ADC resolution, power requirements, and physical dimensions. This manual is written in Japanese.
| Weight (device only) | ≈ 300 g |
|---|---|
| Number of channels | 82 |
| Maximum sampling frequency per channel | 2000 Hz |
| Supported recording media | PC or CompactFlash memory card up to 2 GB |
| Recording format | Japanese Sleep Society PSG common format |
| Dimensions (W × H × D) | ≈ 90 mm × 44 mm × 158 mm |
The AP1132 supports 82 channels, each of which can be configured independently.
Each channel can be sampled up to 2000 Hz, and the rate can be set individually for each channel.
Data can be saved to a PC or to a CompactFlash memory card with capacities up to 2 GB.
