This document is the instruction manual for CS5509, which introduces the features and characteristics of the product.
The CS5509 is a single‑supply, 16‑bit delta‑sigma analog‑to‑digital converter offering up to 200 samples per second. It features on‑chip self‑calibration, high common‑mode rejection, and selectable unipolar or bipolar input ranges, making it suitable for loop‑powered transmitters, panel meters, weigh scales, and battery‑powered instruments.
The device operates from a 3.3 V or 5 V supply, consumes as little as 1.7 mW, and provides a variety of digital interfaces. Detailed electrical characteristics, timing diagrams, and environmental handling information are included for designers.
| Resolution | 16‑bit |
|---|---|
| Maximum Sample Rate | 200 samples/s |
| Power Dissipation | Typical 1.7 mW, Max 2.25 mW |
| Analog Input Range | Unipolar 0‑2.5 V, Bipolar ±2.5 V |
| Common Mode Rejection | 105 dB at 50/60 Hz |
| Input Capacitance | 15 pF |
The CS5509 can update its output at up to 200 samples per second.
Typical power dissipation is 1.7 mW, with a maximum of 2.25 mW.
The device provides 105 dB common‑mode rejection at 50 Hz and 60 Hz.
The CS5509 has a Moisture Sensitivity Level (MSL) rating of 3.
