The Siemens NC 60 2004 7/8 asynchronous motor 1PH7 motors – standard type Shaft heights 100/132 for SIMODRIVE 611 main spindle motors with forced air cooling, various load cycles (in accordance with IEC 60034-1) rated power, order number, standard type, S1, S6-60%, S6-40%, S2 30 minutes.
The Siemens 1PH7 is an asynchronous spindle motor designed for the SIMODRIVE 611 system. It includes selection and ordering data, shaft center height range, rated speed and power, and various mounting options.
The document lists cooling options (forced air cooling), fan types, terminal box connections, bearing specifications, coupling and belt‑drive configurations, and protection ratings (IP55, IP54). It also provides model variants and key dimensions for proper integration. This manual is written in Chinese.
| Shaft center height | 100‑132 mm |
|---|---|
| IP protection rating | IP55, IP54 |
| Fan type | Separate driven fan |
The shaft center height ranges from 100 mm to 132 mm.
The motor is rated IP55 and IP54.
A separate driven fan is supplied.
