Printronix T5000r series industrial barcode label printers are high-quality and high-performance thermal transfer/thermal printers. They feature a 32-bit PowerPC processor and large memory capacity. They support multiple programming languages and can directly accept and print XML commands. In addition, the printer has high reliability and can be remotely managed and monitored.
The T5000r series offers high‑quality thermal‑transfer and direct‑thermal printing with widths of 4, 6 or 8 inches, a 32‑bit PowerPC processor, 32 MB DRAM and up to 16 MB flash for font and image storage, and optional RFID Gen2 upgrades. It supports multiple barcode languages (Zebra, TEC, Intermec, Sato, Datamax) and can receive XML commands for easy integration.
Technical specifications include printing speeds up to 10 inches per second, resolutions of 203 dpi or 300 dpi, memory of 32 MB DRAM with 8 MB flash (standard), print widths up to 8.5 inches, and a range of interfaces such as RS‑232, IEEE 1284, USB 2.0, optional Ethernet, Wi‑Fi and GPIO. The printer operates from 41 °F to 104 °F and weighs between 37 lb and 43 lb depending on model size. This manual is written in Chinese.
| Maximum print speed | 10 inches per second |
|---|---|
| Resolution | 203 dpi or 300 dpi |
| Memory | 32 MB DRAM, 8 MB flash (standard, up to 16 MB) |
| Print width (4" model) | up to 4.1 inches |
| Standard interfaces | RS‑232 Serial, IEEE 1284 (Centronics), USB 2.0 |
| Operating temperature | 41 °F to 104 °F (5 °C to 40 °C) |
| Weight (4" model) | 37 lb (16.8 kg) |
It supports both thermal‑transfer and direct‑thermal printing methods.
Yes, the T5000r can be upgraded on site to an RFID Gen2 printer.
Standard interfaces include RS‑232 Serial, IEEE 1284 (Centronics) and USB 2.0; optional Ethernet, Wi‑Fi and GPIO are also available.
The printer can print up to 10 inches per second.
