XC-SP8GM series is a kind of infrared wireless switch of Fuji Electric, which has the characteristics of anti-frequency and sunlight noise interference, exquisite short tube type, built-in amplifier, can effectively resist harsh working environment, convenient wiring, and provide relay type connectors.
The XC‑SP8GM series is a short‑tube type sensor equipped with a built‑in amplifier and LED indicator. It is designed for use in harsh environments, offering IP67 protection and a wide operating temperature range.
Key specifications include a DC 10‑30 V supply with ≤10 % ripple, a maximum load current of 100 mA, a response time of ≤5 ms, and humidity tolerance of 35‑85 %. The device operates from –20 °C to 5 °C, supports illumination levels from <3000 Lux to >10000 Lux, and features M12 connectors for easy integration. This manual is written in Chinese.
| IP Rating | IP67 |
|---|---|
| Supply Voltage | DC 10‑30 V (ripple ≤10 %) |
| Operating Temperature | -20 °C to 5 °C |
| Relative Humidity | 35 %‑85 % |
| Illumination (Low) | <3000 Lux |
| Illumination (High) | <10000 Lux |
The sensor operates on DC 10‑30 V with ripple not exceeding 10 %.
It is rated IP67 for dust and water protection.
