This manual covers safety warnings, handling precautions and environmental limits for the SSC‑DC series cameras. It explains how to install the unit, connect power and signal cables, and configure synchronization modes.
The document also describes the camera’s key features such as the Exwave HAD CCD sensor, automatic white‑balance, back‑light compensation and activity detection, and lists the power‑supply requirements and signal system for each model. This manual is written in German.
| Signal system (SSC‑DC80P) | PAL, 12/24 V DC |
|---|---|
| Signal system (SSC‑DC83P) | PAL, 12 V DC / 24 V AC 50 Hz |
| Signal system (SSC‑DC88P) | PAL, 220‑240 V AC 50 Hz |
| Alarm output voltage (activity detection) | 0‑5 V |
