The document introduces the functions and characteristics of the SC-260 (EMS)/400 (EMS) upright refrigerated cabinet, including features such as hollow transparent glass door, adjustable temperature, upright appearance, cabinet lighting, and air cooling. It also includes functions such as EMS electronic temperature control, door magnetic switch control of internal fan on/off, and EMS automatic detection of faults.
The manual describes the SC-260/400 (EMS) series upright refrigerated cabinets, which use an EMS‑55 electronic controller, magnetic door switch, and temperature probes to provide precise temperature control and energy‑saving functions. It details the cabinet’s construction, component parts, and the improvements over the previous models, such as removal of the mechanical thermostat.
Technical specifications, wiring diagrams, control parameters, and step‑by‑step maintenance procedures are provided. The document also includes exploded‑view parts lists and part numbers for service and repair. This manual is written in Chinese.
| Effective volume | 280 L (SC‑260) / 350 L (SC‑400) |
|---|---|
| Total volume | 300 L (SC‑260) / 400 L (SC‑400) |
| Rated voltage | 220 V |
| Input power | 340 W (SC‑260) / 500 W (SC‑400) |
| Refrigerant | R134a |
| Net weight | 90 kg (SC‑260) / 101 kg (SC‑400) |
| Dimensions (H × W × D) | 1820 mm × 620 mm × 655 mm (SC‑260) / 2100 mm × 620 mm × 655 mm (SC‑400) |
The cabinets use an EMS‑55 electronic controller that replaces the traditional thermostat.
When the door opens, the magnetic switch stops the internal fan; when the door closes, the fan runs.
The cabinet maintains an internal temperature from 0 °C to 7.2 °C.
The EMS automatically detects faults in the cabinet, system or components and triggers an alarm for maintenance.
