This document introduces the features and characteristics of Dell 5100 MP projector, including connecting the projector, using the projector, and adjusting the projection image.
This manual covers everything needed to install and use the Dell 5100 MP projector. It explains how to connect the projector to computers, DVD players and other sources using a variety of cables (M1‑to‑D‑type, D‑to‑D‑type, HDMI, VGA, etc.), and describes the functions of the control panel, remote, and on‑screen menus.
Additional sections guide you through adjusting image height, focus, zoom and other picture settings, configuring network and RS‑232 control, performing routine maintenance such as lamp replacement, and troubleshooting common issues. A specifications table and a glossary of terms are also included. This manual is written in Chinese.
Use a M1‑to‑D‑type/USB adapter cable or a D‑to‑D‑type cable as described in the connection section.
The projector height can be increased or decreased using the height adjustment controls on the unit.
Press the power button on the control panel to turn the projector on, and press it again to turn it off.
