ViewSonic VX2240w LCD Display is a high-performance, energy-saving and environmentally friendly display with good visual ergonomics and image quality, which can improve the user's working environment and reduce vision and eye strain problems.
This manual covers important safety instructions, quick start installation, optional wall‑mount setup, and detailed technical specifications for the ViewSonic VX2240w 22‑inch LCD display. It also includes troubleshooting tips, cleaning procedures, and warranty details.
The document is organized with a table of contents, followed by sections on safety, installation, specifications, maintenance, and support, making it easy to find the information needed for setup and everyday use. This manual is written in Chinese.
| Screen size | 22 inches |
|---|---|
| Panel type | TFT WSXGA+ LCD |
| Maximum resolution | 1680 × 1050 @ 60 Hz |
| Input signal | RGB analog (0.7/1.0 Vp‑p, 75 Ω) / TMDS digital (100 Ω) |
| Power consumption (typical) | 48 W |
| Dimensions (W × H × D) | 503 mm × 436 mm × 225 mm |
| Weight | 11 lb (5.0 kg) |
| Operating temperature | 32 °F to +104 °F (0 °C to +40 °C) |
| Storage temperature | -4 °F to +140 °F (-20 °C to +60 °C) |
