The PCI-16xx series industrial multi-serial port card is a multi-port serial communication product launched by Zhiyuan Electronics. It can be applied to the traditional RS-232/422/485 serial communication field, quickly expanding the number of PC standard COM communication ports. The PCI-16xx series industrial multi-serial port card provides 2~4 RS-232/422/485 communication ports, and the communication speed of each port can reach 921.64Kbps. The multi-serial port card adopts industrial-grade design, and each communication port integrates anti-surge 30KV ESD protection, and optional high-speed electrical isolation protection. Up to 8 of the same type can be installed on the same PC. The PCI-16xx series industrial multi-serial port card is a reliable choice for multi-port serial communication. PCI-16xx can accelerate the implementation of your serial communication projects and solve the ubiquitous serial communication applications.
The PCI-16xx series is an industrial‑grade PCI card that adds 2 to 4 RS‑232, RS‑422 or RS‑485 serial ports to a PC. Each port supports high‑speed communication up to 921.6 Kbps and includes 30 kV ESD protection, with optional high‑speed electrical isolation rated at 2500 V DC.
The card complies with the PCI 2.2 specification, offers 128‑byte FIFO buffers per port, and works with Windows 2000/XP/Vista as well as Linux. It is designed for use in industrial automation, power‑control communications, telecom equipment, POS systems and office automation. Installation, driver setup, pin definitions and maintenance procedures are detailed in the document. This manual is written in Chinese.
| Number of serial ports | 2–4 |
|---|---|
| Maximum RS‑232 data rate | 921.6 Kbps |
| Maximum RS‑422/485 data rate | 250 Kbps |
| FIFO buffer per port | 128 bytes |
| ESD protection voltage | 30 kV |
| Isolation voltage (optional) | 2500 V DC |
| Operating temperature range | 0 °C ~ 70 °C |
The PCI-16xx series provides between two and four RS‑232/422/485 serial ports.
RS‑232 ports can operate at up to 921.6 Kbps.
The card is rated for operation from 0 °C to 70 °C.
