Promag 50/53 W is an electromagnetic flowmeter suitable for water and wastewater measurement. It features high accuracy, wide measuring range, multiple communication interfaces and modular design.
The Proline Promag 50/53W is an electromagnetic flow measurement system designed for water and wastewater applications. It offers high accuracy, a wide measurement range and various communication options for integration into process control systems.
The document covers the measurement principle, system design, electrical connections, terminal assignments, power supply requirements, communication interfaces (HART, PROFIBUS‑PA, MODBUS‑RS485), output signal options and detailed technical specifications. Installation, wiring diagrams and configuration steps are provided for both integrated and separated transmitter‑sensor configurations. This manual is written in Chinese.
| Maximum Flow Rate | 110000 m³/h |
|---|---|
| Power Supply Voltage (AC) | 85 V – 260 V AC |
| Power Supply Voltage (DC) | 16 V – 62 V DC |
| Frequency Output Range | 2 Hz – 1000 Hz (max 1250 Hz) |
The meter can be powered from 85 V to 260 V AC.
