This is a manual for a FM / SW1-9/MW/LW 12-band receiver with high sensitivity, high selectivity and 12 bands (FM stereo, SW1-9, MW and LW). It adopts a bandwidth spread method that makes it easy to select shortwave broadcasts, and it can be used with stereo headphones (sold separately) to enjoy FM broadcasts in stereo.
The Sony ICF‑SW11 is a 12‑band portable radio (FM, SW1‑9, MW, LW) with high sensitivity and a band‑spread tuning system. It can be powered by two AA batteries or an optional AC adapter and includes a telescopic antenna for improved reception.
The manual covers safety precautions, battery installation, power source selection, basic operation (power, band selection, tuning, volume), headphone use for FM stereo, and warranty information. Technical specifications such as frequency ranges, speaker size, output power, dimensions and weight are listed in the specifications section. This manual is written in Japanese.
| Frequency range (FM) | 87.5 – 108 MHz (Chinese model) / 76 – 108 MHz (other models) |
|---|---|
| Frequency range (SW1) | 4.750 – 5.060 MHz (Chinese model) / 3.850 – 4.050 MHz (other models) |
| Frequency range (MW) | 525 – 1620 kHz |
| Frequency range (LW) | 141 – 290 kHz |
| Speaker diameter | 5.7 cm |
| Power source (battery) | 2 × AA (R6) batteries, 3 V DC |
| Dimensions (W × H × D) | ≈162 × 93.8 × 34.8 mm |
| Mass (incl. batteries) | ≈340 g |
