This manual provides detailed information on the product's features, usage methods, precautions, etc.
This manual provides safety guidelines, installation steps, wiring diagrams and operating instructions for the UDK5114NW2-M driver. It includes checks before use, connection methods, switch functions and troubleshooting advice.
The document also details warranty terms, after‑service contacts, and specifications such as input voltage, temperature limits and grounding requirements. This manual is written in Japanese.
| Input voltage | 100‑115 V AC ±15 % (50/60 Hz) |
|---|---|
| Maximum internal driver temperature | ≤ 80 °C |
| Maximum motor case temperature | ≤ 100 °C |
| Grounding wire size | AWG18 (0.75 mm) or larger |
After turning off the power, wait at least 30 seconds before touching the output terminals to avoid residual voltage.
